NVME Adapter Card PCIE M.2 SSD to PCI-E3.0 1x High Speed Extension M Key NGFF Converter adapter Card for Samsung 960EVO
Bus type: PCI Express x1 Rev3.0
Media interface: 1 x M.2 Key M NVMe SSD connector
M.2 type: 2230, 2242, 2260, 2280
This product requires the motherboard BIOS to support pcie boot. If it does not, the computer cannot recognize the SSD. This product does not support SATA protocol SSD, only NVMe protocol SSD.
This product is only used to test SSD use, 1X bandwidth speed can not reach M.2 4X full speed, if you need to install and start, please carefully consider!
-Allow users to use standard M.2 SSD to desktop PCIe x1/x4/x8/x16 slots,
But the speed is only double.
-Support 2230/2242/2260/2280 type M.2 card size.
-Only supports M.2 Key M SSD based on PCIe X1 slot, does not support M.2 SATA bus B key SSD.
-M.2 NVME to PCIe riser card.
-PCIE interface, support PCI Express rev3.0 1X signal.
-Work in PC desktop office or Game Player.
-Small size and easy to install. (Multiple PCIe interfaces on the motherboard can test multiple SSDs simultaneously)
